Application Scenarios
-
Taxi, online-hailing cars
-
Bus
-
Public charging station
-
Residential community
-
Customized shuttle bus
-
Freight vehicles / Special vehicles
-
Enterprises and institutions
-
Commercial complex
| Item | Cabinet Parameters | |||||||
|---|---|---|---|---|---|---|---|---|
| Basic index | ||||||||
| Model | YLCED40K | YLCED60K | YLCED80K | YLCED120K | YLCED160K | YLCED240K | YLCED320K | YLCED400K |
| Rated power | 40kW (30kW) | 60kW | 80kW | 120kW | 160kW | 240kW | 320kW | 400kW |
| Qty of connector | 1 | 2 | ||||||
| Cooling method | Fan cooling | |||||||
| HMI | 7-inch color screen | |||||||
| Network type | Ethernet/4G | |||||||
| Payment mode | VIN/RFID/Plug&Charge/Credit Card/Scan QR code/Manual (optional) | |||||||
| Dimensions (WxDxH) | 500x390x1600mm (UXR100040) |
700x400x1630mm (NXR75030H/NXR1K020H) |
700x450x1730mm (NXR75030H/NXR1K020H) / 750x460x1750mm (UXR100040/NXR100020) |
750x580x1750mm (UXR100040) |
750x550x1900mm (UXR100040) |
900x900x2350mm (UXR100040) |
||
| Weight (KG) | 100 | 200 | 220 | 270 | 290 | 340 | 390 | 490 |
| Input | ||||||||
| Voltage | 380VAC ± 15%, 3P+N+PE | |||||||
| Frequency | 45Hz-65Hz | |||||||
| Current | 64A | 97A | 129 A | 194 A | 259 A | 387A | 516A | 644A |
| Power factor | ≥0.99 | |||||||
| ITHD | ≤5% | |||||||
| Output | ||||||||
| Voltage range | 200-1000Vdc | 200-750Vdc / 200-1000Vdc | 200-1000Vdc | |||||
| Constant power range | 300-1000Vdc | 400-750Vdc / 300-1000Vdc | 300-1000Vdc | |||||
| Max current per connector | 133A | 150A/200A | 200A/250A | 250A | ||||
| Max efficiency | >95% | |||||||
| Output voltage error | ≤±0.5% | |||||||
| Output current error | ≤±1% | |||||||
| Voltage stabilized accuracy | ≤±0.5% | |||||||
| Current stabilized accuracy | ≤±1% | |||||||
| Peak-peak ripple | ≤±1% | |||||||
| Environment | ||||||||
| Operating temperature | -20 ~ +50°C | |||||||
| Storage temperature | -40 ~ +75°C | |||||||
| Operating environment | Indoor or outdoor (IP54) | |||||||
| Humidity | 5~95%RH, non-condensing | |||||||
| Altitude | 2000m no derating required;>2000m, the working temperature decreases by 1°C for every 100m rise | |||||||
| Item | Terminal Parameters | |||||||
|---|---|---|---|---|---|---|---|---|
| Basic index | ||||||||
| Model | YLCED40K | YLCED60K | YLCED80K | YLCED120K | YLCED160K | YLCED240K | YLCED320K | YLCED400K |
| Rated power | 40kW (30kW) | 60kW | 80kW | 120kW | 160kW | 240kW | 320kW | 400kW |
| Qty of connector | 1 | 2 | ||||||
| Cooling method | Fan cooling | |||||||
| HMI | 7-inch color screen | |||||||
| Network type | Ethernet/4G | |||||||
| Payment mode | VIN/RFID/Plug&Charge/Credit Card/Scan QR code/Manual (optional) | |||||||
| Dimensions (WxDxH) | 500x390x1600mm (UXR100040) |
700x400x1630mm (NXR75030H/NXR1K020H) |
700x450x1730mm/750x460x1750mm | 750x580x1750mm (UXR100040) |
750x550x1900mm (UXR100040) |
900x900x2350mm (UXR100040) |
||
| Weight (KG) | 100 | 200 | 220 | 270 | 290 | 340 | 390 | 490 |
| Input | ||||||||
| Voltage | 380VAC ± 15%,3P+N+PE | |||||||
| Frequency | 45Hz-65Hz | |||||||
| Current | 64A | 97A | 129 A | 194 A | 259 A | 387A | 516A | 644A |
| Power factor | ≥0.99 | |||||||
| ITHD | ≤5% | |||||||
| Output | ||||||||
| Voltage range | 200-1000Vdc | 200-750Vdc / 200-1000Vdc | 200-1000Vdc | |||||
| Constant power range | 300-1000Vdc | 400-750Vdc / 300-1000Vdc | 300-1000Vdc | |||||
| Max efficiency | >95% | |||||||
| Output voltage error | ≤±0.5% | |||||||
| Environment | ||||||||
| Operating temperature | -20 ~ +50°C | |||||||
| Storage temperature | -40 ~ +75°C | |||||||
| Operating environment | Indoor or outdoor (IP54) | |||||||
| Humidity | 5~95%RH,non-condensing | |||||||
| Altitude | 2000m no derating required;>2000m,the working temperature decreases by 1 °C for every 100m rise | |||||||
